Postgres Internals Under the Hood: Database Clusters, Databases, and Table File Layout

Key Takeaways

• $PGDATA is not a database — it’s the entire cluster root. Every database lives inside its base/ subdirectory, named by its OID, not its name.
• Tables are not isolated files. Each table is backed by at least one relfilenode file; when it exceeds 1GB, Postgres splits it into relfilenode.1, relfilenode.2 segment files.
• OID is the key to everything. pg_database OIDs determine directory names under base/; pg_class.relfilenode determines table filenames. Skip this mapping and you’ll be debugging blind.
• Tablespaces break your directory assumptions. Custom tablespaces relocate table files out of base/ into symlinked paths under pg_tblspc/ — a classic disk-usage investigation trap.
• ALTER TABLE ADD COLUMN with a default does NOT rewrite old rows. The default lives in pg_attrdef, computed at read time. That’s why some ALTERs return instantly and others stall for ages.

Let me start with a painful memory. Last month our staging box’s disk started screaming. du -sh showed one database eating 47GB — I nearly had a heart attack assuming some business table exploded. But after digging into base/, the real culprit was the leftover file of a long-dropped table. The relfilenode file was still on disk because some session was holding a snapshot, and VACUUM had no right to clean it up. Unless you understand Postgres’ storage layout, you’ll be fumbling around with pg_relation_filepath() trying every table name like a madman.

So let’s strip Postgres’ physical storage layer down to the bone. From cluster initialization all the way to table files, and then we talk about the traps.

Database Cluster: One $PGDATA Is a Small Universe

One of the most confusing concepts in Postgres is the “database cluster.” Most people hear “cluster” and think multiple machines. In Postgres land, a cluster is just the output of initdb. It contains:

• A $PGDATA root directory
• Several databases (default: postgres, template0, template1)
• A shared pg_global tablespace (for cross-database system catalogs like pg_database)
• A WAL directory (pg_wal/)
• Config files (postgresql.conf, pg_hba.conf, etc.)

A single cluster listens on one port by default (5432). If you want multiple “isolated” instances on one machine, you initialize multiple $PGDATA directories, each on its own port — this is the core of the eternal question “PostgreSQL database cluster vs. single server with many databases.” Multiple databases share the same process pool, WAL, and buffer pool. Multiple clusters are completely isolated process groups. The former saves resources; the latter gives you stronger isolation and independent upgrades, but doubles your maintenance overhead.

After initdb, your $PGDATA looks roughly like this:

$ ls -F $PGDATA
base/    global/    pg_commit_ts/    pg_dynshmem/    pg_wal/    postgresql.conf
pg_hba.conf    PG_VERSION    postmaster.opts    postmaster.pid    ...

Pay attention to base/ and global/. global/ holds cluster-wide shared system catalogs; base/ holds one subdirectory per database.

Databases: The Numeric Naming Game Under base/

Postgres assigns each database an OID (Object Identifier, an unsigned 32-bit integer). Under base/, each database maps to a subdirectory named by that OID:

$ ls -F $PGDATA/base/
1/    13010/    13011/    13012/

1 is template1’s OID; 13010 might be postgres; the rest are databases you created. Verify directly:

SELECT oid, datname FROM pg_database;

Output:

  oid  |  datname
-------+-----------
     1 | template1
 13010 | postgres
 13011 | myapp
 13012 | analytics

See? The directory names under base/ map 1:1 to OIDs. When you read a blog post saying “this file base/5/16384 is something,” you should immediately think: 5 is a database’s OID, 16384 is a table’s relfilenode in that database.

Here’s the counterintuitive part: database directory names are not database names. If you search by name, you will never find the directory. That’s why so many people are baffled when they first poke around base/.

Another trap: OIDs can be reused. The 32-bit space is huge, but if your system churns through databases aggressively, OIDs can wrap around. Postgres ships oid2name to map OIDs back to names:

$ oid2name
All databases:
    OID  Database Name  Tablespace
 13010  postgres         pg_default
 13011  myapp            pg_default

Honestly, oid2name is criminally underused. It’s genuinely useful for file-ownership forensics. I’d even suggest saving its output as a cheat sheet near your workstation.

Tables: relfilenode Is the Real Name on Disk

Every table has a file in its database directory, named by the table’s relfilenode value. This value usually equals the table’s OID — but not always. VACUUM FULL, CLUSTER, and REINDEX rewrite tables and assign new relfilenodes. Never assume OID == filename.

Query it:

SELECT relname, relfilenode, oid FROM pg_class WHERE relname = 'users';

 relname | relfilenode |  oid
---------+-------------+-------
 users   |       24650 | 24650

Then grab the full path:

SELECT pg_relation_filepath('users');

 pg_relation_filepath
----------------------
 base/13011/24650

That’s the real on-disk location. Peek at it:

$ ls -lah $PGDATA/base/13011/
-rw------- 1 postgres postgres 8.2M Aug  7 01:23 24650
-rw------- 1 postgres postgres 24K  Aug  7 01:23 24650_fsm
-rw------- 1 postgres postgres 8.2K Aug  7 01:23 24650_vm

_fsm is the Free Space Map, _vm is the Visibility Map. These are auxiliary files, but don’t delete them. Postgres will rebuild them, but performance dips during the rebuild, and if you hit a crash-recovery window at exactly the wrong moment, you can end up with inconsistent data.

Tables Over 1GB Get Split Into Segments

Postgres’ default segment_size is 1GB (compile-time constant — SHOW block_size for block size, SHOW segment_size for segment size). Once a table exceeds 1GB, Postgres generates 24650.1, 24650.2 suffix files:

$ ls -lah $PGDATA/base/13011/
-rw------- 1 postgres postgres 1.0G Aug  7 01:23 24650
-rw------- 1 postgres postgres 1.0G Aug  7 01:23 24650.1
-rw------- 1 postgres postgres 682M Aug  7 01:23 24650.2

This mechanism exists purely to dodge filesystem single-file size limits. You don’t need to manage it manually — Postgres handles cross-segment addressing transparently. But backup tools (like manually tar-ing the entire data directory) must be aware: copying only 24650 without .1 and .2 produces a truncated table on restore, and pg_checksums might not even catch it (file sizes look legal; data is just missing).

Indexes Are Files Too

Indexes don’t live inside the table file. Each index has its own relfilenode file. So a “table + 5 indexes” costs 6 files (plus FSM/VM). A lot of people check pg_total_relation_size() and still underestimate how badly indexes can bloat. I’ve seen production tables at 20GB with 31GB of indexes — that alone can melt your buffer pool.

Tablespaces: The Exception That Breaks the base/ Assumption

Postgres supports custom tablespaces, letting you place data on other disk paths. Once you use a tablespace, table files no longer live under base/; they live under:

$PGDATA/pg_tblspc/16386/

16386 is the tablespace’s OID. Note that pg_tblspc/ contains not real directories but symlinks pointing to the path you specified at creation:

$ ls -l $PGDATA/pg_tblspc/
lrwxrwxrwx 1 postgres postgres 15 Aug  7 01:00 16386 -> /ssd/postgres_data

The upside: you can move data from HDD to SSD without moving a byte — just repoint the symlink. The downside: if you tar up $PGDATA but forget /ssd/postgres_data, your restore is doomed. Postgres starts up, hits a dangling symlink, and throws could not open file with only an OID in the message. You’ll need oid2name to reverse-engineer what that OID means.

I strongly recommend that any backup script handling custom tablespaces also verify the tablespace’s real path. Don’t ask me how I know.

Reading a Table File: 8KB Pages and Heap Tuples

Now you know where table files live. But what’s inside? Postgres divides table files into fixed-size pages (default 8KB — confirm with SHOW block_size). Each page’s internal structure:

• PageHeaderData (24 bytes) — page metadata, including checksum (if data_checksums is enabled), free-space start offset, special-space start offset.
• ItemIdData array — pointer array growing from the page header toward the tail; each pointer references a tuple’s actual position.
• Free space — the gap between the header pointer array and the tail tuple data.
• HeapTupleData array — tuple data growing from the page tail toward the header; each tuple carries system columns like t_xmin, t_xmax, t_ctid.
• Special space — page end, typically for index pages (e.g., B-tree highkey).

This layout directly drives Postgres’ MVCC: updating a row is not overwriting old data — it’s inserting a new version, leaving the old version for older transactions. t_xmin and t_xmax define the visibility boundary.

Sequential Scan vs. Index Scan

For reading a row, Postgres has two typical access paths:

1. Sequential Scan (Seq Scan) — reads from page 0 to the end, one page at a time. For small tables, this beats index scans because index scans involve two random I/Os (look up index, then fetch heap page), while sequential scans are linear prefetch-friendly.
2. Index Scan — walks the B-tree to find matching ctids, then fetches the corresponding heap pages. For fetching a few rows from a large table, it’s the only sensible choice.

The planner picks a path by estimating costs from relpages and reltuples statistics, which come from ANALYZE. If you load a huge batch of data and forget to ANALYZE, the planner uses stale reltuples, and suddenly queries that should use an index go full sequential scan — P99 spikes to multiple seconds. I’ve seen this exact scenario too many times.

Table, Page, and Tuple Performance Trade-offs

Here’s a truth that gets ignored: Postgres’ tuple size limit is page size minus header overhead — with 8KB pages, one row maxes out at roughly 8KB minus ~24 bytes of page header minus ~23 bytes of tuple header. Insert a row exceeding that and Postgres throws row is too big. Large fields like TEXT, JSONB, BYTEA get compressed (if COMPRESSION is enabled) or moved to a TOAST table (The Oversized-Attribute Storage Technique).

TOAST tables are independent tables with their own relfilenode. So a table’s true disk cost includes its TOAST table and TOAST index. pg_relation_size('users') returns only the main table; pg_total_relation_size('users') includes TOAST and all indexes.

Keep this table handy for backups and disk forensics.

Alternatives and Trade-offs: Why Not MySQL or Single-File Databases?

You might ask: why bother with all this complexity? Why not be like SQLite with one file per database? Postgres’ multi-directory design has costs and rewards:

• Reward: multiple databases share one buffer pool, improving memory utilization; WAL is cluster-wide, so crash recovery replays a single log.
• Cost: cross-database queries (dblink, postgres_fdw) perform terribly because they go over the wire protocol even locally. If you need frequent cross-database JOINs, the design should put related tables in the same database — split tenants by database, not features.
• vs. MySQL: MySQL’s datadir also has one directory per database, but table files are named tablename.frm / tablename.ibd — far more human-readable than Postgres’ OID naming. Postgres’ OID naming is purely historical baggage, but the payoff is that ALTER TABLE ... RENAME doesn’t touch physical files — just updates a pg_class row, instant.

FAQ

Q: What’s the difference between a PostgreSQL database cluster and multiple databases on a single server?

A: A cluster is one complete initdb instance, containing multiple databases that share one WAL and one memory pool, listening on one port by default. A single server can run multiple clusters (multiple $PGDATA, multiple ports), but they’re independent process groups sharing no memory or WAL. Clusters save resources internally; clusters provide stronger isolation and independent upgrades.

Q: Why are directory names under base/ numeric instead of database names?

A: Because the directory names are database OIDs (object identifiers), not names. Postgres uses OIDs as primary keys for all metadata; names are just a field in pg_database. This lets ALTER DATABASE ... RENAME work without moving physical directories.

Q: Why does the table file change after VACUUM FULL?

A: VACUUM FULL rewrites the entire table, copying live tuples to a new file and deleting the old one. The process assigns a new relfilenode, so the file path changes. Regular VACUUM only cleans dead tuples, never changes relfilenode, but also never returns disk space to the OS.

Q: What happens when a table exceeds 1GB?

A: Postgres splits the table into segment files named relfilenode, relfilenode.1, relfilenode.2, and so on. This handles filesystems with single-file size limits. Reads and writes are transparent to the application, but backup tools must capture all segments.

Q: Why does pg_relation_filepath() return a path different from what’s under base/?

A: If you use a custom tablespace, pg_relation_filepath() returns a path like pg_tblspc/<tablespace_oid>/<database_oid>/<relfilenode> instead of base/<database_oid>/<relfilenode>, because the table file physically lives at the tablespace’s target location.

References & Community Insights

There’s been a lively Hacker News thread recently about AI-generated images in technical blogs, and the comments are brutally split — half the people say flashy illustrations actively repel them, the other half say pure text is too dry. I’m firmly in the pure-text camp, especially for low-level Postgres source analysis — a botched AI diagram is worse than a terminal screenshot. The thread itself reflects a broader reality: the technical community is increasingly impatient with surface polish; people want directly actionable substance. That aligns perfectly with how we debug base/ — skip theory, hit the wall, then read the theory.

Here are a few resources I’ve leaned on heavily recently, and they’ve genuinely saved me:

• The Internals of PostgreSQL — Chapter 1: Database Cluster, Databases and Tables — the most systematic illustrated treatment; read it end to end.
• PostgreSQL Official Docs: Database File Layout — mediocre prose but authoritative; settle disputes against it.
• Hacker News discussion on PostgreSQL internals — real users sharing war stories, far livelier than the docs, especially for the traps that aren’t documented but you will hit.
